MSC60CAS Auto ac compressor clutch hub for SUZUKI Swift SX4 FIAT size 94*14*1.6 mm 95200-62JA0
MSC60CAS Auto ac compressor clutch hub for SUZUKI Swift SX4 FIAT size 94*14*1.6 mm 95200-62JA0
Model
HY-XP138

Item specifics

original
China
Car model
SUZUKI Swift SX4 FIAT
Compressor type
MSC60CAS
OEM
95200-62JA0 71743779
outer diameter max:
94mm
total thickness:
14mm
the height of the mandrel from the friction surfa:
1.6mm
dimension of the groove / manifold / thread:
9.5x18x0.5 mm

Review

Description

Wholesale price MSC60CAS automotive air conditioning compressor clutch hub for

SUZUKI Swift SX4 FIAT size 94*14*1.6 mm 95200-62JA0 71743779


HYoung ID: HY-XP138

Clutch disc compressor / air conditioning compressor MITSUBISHI MSC60CAS

SUZUKI

FIAT

dimensions:

A - outer diameter max.,

B - total thickness,

C - the height of the mandrel from the friction surface,

D - dimension of the groove / manifold / thread



A = 94 mm

B = 14 mm

C = 1.6 mm

D = 9.5x18x0.5 mm



Application:

SUZUKI Swift III / SX4

SUZUKI SWIFT 1.3 petrol 92HP 2006 4x4

SUZUKI SX4 1.6 VVT 2006 -

SUZUKI Swift III 1.3 MZ EZ 2006- 1328ccm M13A

SUZUKI Swift III 1.5 MZ EZ 2005- 1490ccm M15A

SUZUKI Swift III 1.6 MZ EZ 2006- 1586ccm M16A

SUZUKI SX4 1.5 GY 2006- 1490ccm M15A

SUZUKI SX4 1.6 GY 2006- 1586ccm M16A



OEM numbers of the compressors:

Mitsubishi AKC201A083A

Mitsubishi AKC200A083A

Mitsubishi AKC011H088

Suzuki 95200-62JA0

Fiat 71743779
