Auto a/c Blower fan motors Caterpillar 2688792 150-3351 123641 1503351
- Model
- HY-FM158
Item specifics
- Brand name
- TUYOUNG
- Voltage
- 24V
- OEM
- 2688792 150-3351 123641 3246125 1503351
- car model
- Caterpillar Grader 140M3, 140M2 series exvacator
Review
Description
China factory manufacture car air conditioner blower fan motor for Caterpillar 24V Excavator
TUYoung ID: HY-FM158
Specification
Voltage: 24V
TYPE: Single Shaft with blower wheel
Rotation CW
Voltage 24
Motor Diameter (mm) 76
Wire Qty 2
Wheel Diameter (mm) 175
Motor Length (mm) 108
SHAFT SIZE: 3/8", 10MM;
SHAFT LENGTH: 3 3/4", 95MM;
MOTOR DIAMETER: 3″, 76MM;
MOTOR LENGTH: 4 1/4″, 108MM;
Wheel Diameter: 6 7/8", 175mm;
Wheel Length: 3 3/8", 86mm;
Overall Length with Wheels: 7 3/4", 197mm
NUMBER OF WIRES: 2 ;
VOLTAGE: 24V
STUD SPAN: 2 5/16″
OEM NO.:
150-3351
123641
1503351
2688792
BM3503
2688792
2613482
BM 10168
Suitable for
Caterpillar Excavator
Caterpillar Grader 140M3, 140M2 series exvacator
