Model
HY-TL241

Item specifics

brand
TUYoung
Maximum pressure
50MPa
Working method
manual hydraulic
Dimensions
54*17*8CM
Net weight
8kg
Core types
No. 3, No. 4, No. 5, No. 6

Review

Description

brand new Riveting of car a/c pipe head with China factory price





Product No.: HY-TL241


Details:
A Application: Riveting of automobile air-conditioning pipe head

B Specifications:
1. Maximum pressure: 50MPa;
2. Working method: manual hydraulic
3. Dimensions: 54*17*8CM
4. Net weight: 8kg

C Scope of application:
aluminum sleeve, alloy aluminum sleeve, iron sleeve
Core: No. 3, No. 4, No. 5, No. 6

D use steps:
1. Put the high-pressure pipe and the aluminum sleeve with the pile into the mold core, and adjust the correct position (the aluminum sleeve should be set to the position)
2. Turn the switch nut clockwise to the end
3. Press down the handle, at this time 8 cores are squeezed towards the center at the same time, until the cores are closed
4. Rotate the switch nut counterclockwise to the end, the hydraulic handle will automatically return, the mold core will be released, and return to the initial position
5. Take out the pressed pipeline
