Top-mounted Unit. 24V automotive air conditioning components, roof-mounted integrated air conditioning
- Model
- HY-RAC30
Item specifics
- Brand name
- TUYOUNG
- Power Supply
- DC/24V
- Input Voltage Range
- 22V-30V
- Rated Power
- 650W
- Rated Current
- 32A (35°C)
- Effective Cooling Capacity
- 2200W
- Compressor
- Yuanqing Scroll
- Maximum Airflow
- 450m³/h
- Indoor Unit Fan
- 24V Brushed Evaporator Fan
- Condenser Fan
- 24V brushed electric fan
- Controller
- Intelligent Inverter Controller
- Air Outlet
- Oscillating Electric Air Outlet (Four-way Adjustment)
- Operating Temperature
- 18°C ~ 43°C
- Refrigerant
- R134A
- Refrigerant Charge
- 600g
Review
Description
TUYOUNG 24V automotive air conditioning parts, Dual Fans Roof air conditioner
TUYOUNG ID: HY-RAC30
Product Parameters:
Power Supply: DC/24V
Input Voltage Range: 22V-30V
Rated Power: 650W
Rated Current: 32A (35°C)
Effective Cooling Capacity: 2200W
Compressor: Yuanqing Scroll
Maximum Airflow: 450m³/h
Indoor Unit Fan: 24V Brushed Evaporator Fan
Condenser Fan: 24V Brushed Electric Fan
Controller: Intelligent Inverter Controller
Air Outlet: Oscillating Electric Air Outlet (Four-way Adjustment)
Operating Temperature: 18°C ~ 43°C
Refrigerant: R134A
Refrigerant Charge: 600g
Evaporator Specifications: 340X126X52mm, 24 copper tubes, three inlets and three outlets
Condenser Specifications: 495X340X25.4mm Parallel Flow
Packaging Dimensions: 1080*950*470mm
External Dimensions: 975X830X175mm
Window size: Minimum 530X350mm, Maximum 690X350mm
Power cord: 8 sq mm positive and negative red and black wire (6 meters with plug-in) with 80A fuse
Total weight: 38.7kg
