CR12S Auto ac compressor clutch hub for Nissan Navara Pathfinder 92600-EB400 size 109.6*54.3*38.6 mm
- Model
- HY-XP107
Item specifics
- original
- China
- Car model
- Nissan Navara Pathfinder
- Compressor type
- CR12S CR14
- OEM
- 92600-EB400
- outer diameter max:
- 109.6mm
- total thickness:
- 54.3mm
- the height of the mandrel from the friction surfa:
- 38.6mm
- dimension of the groove / manifold / thread:
- 12.3 mm
Review
Description
China factory supply CR12S CR14 automotive air conditioning compressor clutch hub for Nissan Navara Pathfinder 92600-EB400 size 109.6*54.3*38.6 mm
HYoung ID: HY-XP107
Clutch / compressor clutch disc CALSONIC
CR-12S
CR-14
dimensions:
A - outer diameter max.,
B - total thickness,
C - the height of the mandrel from the friction surface,
D - dimension of the groove / manifold / thread
A = 109.6 mm
B = 54.3 mm
C = 38.6 mm
D = 12.3 mm
Application:
NISSAN Navara 2.5 dCi D40 2005- 2488ccm
NISSAN Pathfinder 2.5 dCi D40 2005- 2488ccm
OEM :
A42011A0702001
92600-EB400
92600-EB40B
92600-EB40E
A42011A0702003
A42011A0702100
A42011A0702200
