CVC ac compressor clutch hub for Opel Astra Meriva Insignia size 86*25*15 mm 13250606 687997689
- Model
- HY-XP90
Item specifics
- original
- China
- Car model
- Opel Astra Meriva Insignia
- Compressor type
- CVC
- OEM
- 13250606 687997689
- outer diameter max:
- 86 mm
- total thickness:
- 25 mm
- the height of the mandrel from the friction surfa:
- 15 mm
- dimension of the groove / manifold / thread:
- 12.5 × 24 × 0.5 mm
Review
Description
China factory manufacture CVC automotive air conditioning compressor
clutch hub for Opel Astra Meriva Insignia size 86*25*15 mm 13250606 687997689
HYoung ID: HY-XP90
CVC Clutch disc compressor / air conditioning compressor DELPHI
dimensions:
A - outer diameter max.,
B - total thickness,
C - the height of the mandrel from the friction surface,
D - dimension of the groove / manifold / thread
A = 86 mm
B = 25 mm
C = 15 mm
D = 12.5 × 24 × 0.5 mm
Multi-blade disc
Application:
OPEL Astra J 1.4 2009-2012 1398ccm A14XEL A14XER
OPEL Astra J 1.4 Turbo 2009-2012 1364ccm A14NEL A14NET
OPEL Astra J 1.3 CDTi 2009-2012 1248ccm A13DTE
OPEL Astra J 1.7 CDTI 2010-2012 1686ccm A17DT ..
OPEL Meriva B 1.4 2010-2012 1364ccm A14NEL A14NET
OPEL Meriva B 1.4 2010-2012 1398ccm A14XER
OPEL Meriva B 1.3 CDTI 2010-2012 1248ccm A13DTC A13DTE
OPEL Meriva B 1.7 CDTI 2010-2012 1686ccm A17DT ..
OPEL Zafira B 1.7 CDTI A05 2008-2011 1686ccm A17DTJ A17DTR
OPEL Insignia 1.6 2008- 1598ccm A16XER
OPEL Insignia 1.6 Turbo 2008- 1598ccm A16LET Z16LET
OPEL Insignia 1.8 2008- 1796ccm Z18XER
OPEL Insignia 2.0 Turbo 2008- 1998ccm A20NFT A20NHT
SAAB 9-5 II 2.0t YS3G 2010- 1998ccm A20NFT A20NHT
CHEVROLET Cruze 1.4 2012-2012 1362ccm LUJ
OEM:
Opel 13250606
Opel 1618422
Opel P1618422
Opel 13395693
Opel P1618047
Opel 1618047
Chevrolet-Daewoo 13271268
Chevrolet-Daewoo 13250608
Chevrolet-Daewoo 13346489
Chevrolet-Daewoo P1618063
Chevrolet-Daewoo 1618063
Chevrolet-Daewoo 13220076
Chevrolet-Daewoo 687997689
Chevrolet-Daewoo P6854113
Chevrolet-Daewoo 22751939
Chevrolet-Daewoo 6854113
Chevrolet-Daewoo 13314480
Delphi-Harrison 114150500
Delphi-Harrison 117250791
Delphi-Harrison 106290114
Delphi-Harrison 1140863
Delphi-Harrison 1140861
Opel 13271269
Opel 13262843
Opel 13250609
Sanden 1603P
Sanden 1603
Opel 13262836
Opel 13232305
Opel 6854109
Opel 13250607
1618415
1140865
1618424
13395695
95516237
13271266
0609DPSS
0607DPSS
0608DPSS
