5TSE10C AUTO AC Compressor clutch hub Toyota Vitz Yaris size 110*37*10.5 mm 88310-02840 447280-6600
5TSE10C AUTO AC Compressor clutch hub Toyota Vitz Yaris size 110*37*10.5 mm 88310-02840 447280-6600
Model
HY-XP82

Item specifics

original
China
Car model
Toyota Vitz Yaris
Compressor type
5TSE10C
OEM
88310-02840 447280-6600
outer diameter max:
110 mm
total thickness:
37 mm
the height of the mandrel from the friction surfa:
mm
dimension of the groove / manifold / thread:
10.5 mm

Review

Description

China factory supply 5TSE10C automotive air conditioning compressor

clutch hub for Toyota Vitz Yaris size 110*37*10.5 mm 88310-02840 447280-6600


HYoung ID: HY-XP82


5TSE10C Compressor / DENSO air compressor clutch disc

dimensions:
A - outer diameter max.,
B - total thickness,
C - the height of the mandrel from the friction surface,
D - dimension of the groove / manifold / thread

A = 110 mm
B = 37 mm
C = -
D = 10.5 mm

Application:
TOYOTA Verso S 1.33 NLP12 NCP12 2010- 1329ccm 1NR-FE
TOYOTA Yaris III 1.33 ..P13 2010- 1329ccm 1NR-FE
TOYOTA Yaris III 1.0 ..P13 2011- 0998ccm 1KR-FE
TOYOTA Yaris III 1.4 D-4D ..P13 2011- 1364ccm 1ND-TV
Toyota Vitz 1.3i 1NR-FE 12.10 -
Toyota Echo 1.3i 1NR-FE 12.10 -
Toyota Auris 1.4 D4D 1ND-TV 02.13 -

OEM:
Toyota 88310-02840
Toyota 88310-0D380
Denso 447260-4201
Denso GE447260-4202
Denso 447280-6590
Denso GE447280-6600
Denso 447260-4202
Denso GE447260-4201
Denso 447280-6600
Denso GE447280-6590
88310-0D420
447150-3300
447260-4201
447280-6600
88310-0D410
88310-52730
88310-52780
248300-3060
447150-2320
447260-4200
88310-0D380
88310-52710
