SCS06 SCSA06 auto ac compressor clutch hub Subaru Outback Toyota Corolla Alfa Romeo Fiat 71721727
- Model
- HY-XP70
Item specifics
- original
- China
- Car model
- Subaru Outback Toyota Corolla Alfa Romeo Fiat
- Compressor type
- SCS06 SCSA06
- OEM
- 447100-1430 71721727
- outer diameter max:
- 94mm
- total thickness:
- 24.9 mm
- the height of the mandrel from the friction surfa:
- 16.8 mm
- dimension of the groove / manifold / thread:
- 13.5x25x0.5 mm
Review
Description
wholesale price SCS06 SCSA06 automotive air conditioning compressor
clutch hub for Subaru Outback Toyota Corolla Alfa Romeo Fiat 71721727
HYoung ID: HY-XP70
SCS06
SCSA06
SCSB06
Compressor / DENSO air compressor clutch disc
dimensions:
A - outer diameter max.,
B - total thickness,
C - the height of the mandrel from the friction surface,
D - groove / manifold dimension
A = 94 mm
B = 24.9 mm
C = 16.8 mm
D = 13.5x25x0.5
Shield for wedge
Application:
ALFA ROMEO Alfa 145 1.4 930 1994-1996 1351ccm AR33501
ALFA ROMEO Alfa 145 1.4 16V T.SPARK 930 1996-2001 1370ccm AR33503 AR38501
ALFA ROMEO Alfa 146 1.4 930 1994-1996 1351ccm AR33501
ALFA ROMEO Alfa 146 1.4 16V T.SPARK 930 1996-2001 1370ccm AR33503 AR38501
ALFA ROMEO Alfa 147 1.9 JTD 8V 937 2001-2005 1910ccm 937A2000
ALFA ROMEO Alfa 147 1.9 JTDM 16V 937 2004- 1910ccm 192B1000
ALFA ROMEO Alfa 156 1.9 JTD 8V 932 2005- 1910ccm 937A2000
ALFA ROMEO Alfa GT 1.9 JTD 937 2005- 1910ccm 937A5000
FIAT Brava 1.9 JTD 105 182 1998-2001 1910ccm 182B4.000
FIAT Bravo I 1.9 JTD 105 182 1998-2001 1910ccm 182B4.000
FIAT Bravo II 1.6 D Multijet 198 2007- 1598ccm 198A2.000 198A3.000 198A4.000
FIAT Bravo II 1.9 D Multijet 198 2006- 1910ccm 937A5.000
FIAT Stilo 1.8 16V 192 2001-2007 1747ccm 192A4.000
FIAT Stilo 1.9 D Multijet 192 2005-2007 1910ccm 192A8.000 192A9.000
FIAT Stilo 1.9 JTD 192 2002-2007 1910ccm 192A3.000
FIAT Doblò I 1.9 D 119 223 2000- 1910ccm 223A 6000
FIAT Doblò I 1.9 JTD 119 223 2003- 1910ccm 223B1.000 223A7.000
FIAT Palio 1.9 D 178 2001- 1910ccm 223A6.000
FIAT Punto II 1.9 JTD 2001-2003 1910ccm 188A2.000 188A7.000
FIAT Strada 1.9 D 178 2003- 1910ccm 188A2.000
FIAT Strada 1.9 D 178 2000- 1910ccm 223A6.000
TOYOTA Corolla 1.4 VVT-i ..E12 .. 2002-2007 1398ccm 4ZZ-FE
TOYOTA Corolla 1.6 VVT-i ..E12 .. 2002-2007 1598ccm 3ZZ-FE
TOYOTA Corolla 1.8 VVT-i ..E12 .. 2002-2007 1796ccm 2ZZ-GE
TOYOTA Corolla Verso 1.6 .. E12 .. 2004-2009 1598ccm 3ZZ-FE
SUBARU Legacy IV 2.0 2003-2009 1994ccm EJ20.
SUBARU Legacy IV 2.0 Turbo R 2007-2009 1994ccm EJ204
SUBARU Legacy IV 2.5 2003-2009 2457ccm EJ25.
SUBARU Legacy V 2.0i AWD 2009- 1994ccm EJ204
SUBARU Legacy V 2.5i AWD 2009- 2457ccm EJ253
SUBARU Outback 2.0 BL BP 2003-2005 1994ccm EJ20.
SUBARU Outback 2.5i 16V BL BP 2003-2009 2457ccm EJ25.
SUBARU Outback 2.5i AWD BM BR 2009- 2457ccm EJ25.
OEM :
46757907
442100-1026
447100-1430
447170-0690
447260-7000
46786262
467862620
50777-5200
507775100
507775200
59247-5700
59247-6000
59247-6002
60654446
60659643
60814720
60815788
71721727
71721737
71721738
592475700
592476000
51752531
247300-0621
447160-8960
447170-8960
447200-8642
447220-8640
447220-8641
447220-8642
447220-8643
447220-8644
447220-8645
447220-8646
46811244
5A7975000
71721741
447100-1954
447100-1950
447100-1951
447100-1952
447100-1953
447180-9220
447180-9221
447180-9222
447180-9223
447180-9224
447200-6360
447220-6352
447220-6353
447220-6361
447220-6362
447220-6364
88310-1A580
88310-1A582
88320-1A481
88320-1A550
447180-9330
447260-7940
447260-7941
447260-7942
73111-AG000
73111-AG001
73111-AG030
